Saturday, December 28, 2013

Polygon Cozmic CX 2.0

Frame: ALX Alloy Cross Country, 9x135mm
Front Fork: SR Suntour XCR32-LO, Travel 100mm, 1-1/8” Steerer
Shift Lever: Shimano Deore SL-M610
Derailleur Front: Shimano Deore FD-M610
Derailleur Rear: Shimano Deore RD-M610SGS
Brakes Front: Shimano Acera BR-M395
Brakes Rear: Shimano Acera BR-M395
Brake Levers: Shimano Acera BL-M395
Pedals: VP Component VP-199, Alloy
Crankset: Shimano Deore FC-M610, 170mm(S-M), 175mm(L), 42x32x24T
Bottom Bracket: Shimano Hollowtech 2
Chain: Shimano Deore CN-HG54
Cassette: Shimano Deore CS-HG62, 11-36T
Hub Rear: Shimano FH-RM35
Hub Front: Shimano HB-RM35
Rim: Araya DM-650, Double wall
Spokes Nipples: Stainless Steel Spokes
Tires: Schwalbe Smart Sam, 27.5”x2.10”
Saddle: Entity Flux Saddle, Steel Rail
Seatpost: Entity Xpert, Alloy, 30.9x350mm
Stem: Entity Xpert, Alloy, 90mm(S-M), 110mm(L)
Handlebar: Entity Xpert, Alloy, 680mm
Headset: Entity Integrated Sealed Bearing

Thursday, November 28, 2013

Merida Big Seven Carbon XT Edition


Colors : white blue
Framesizes : 15" / 17"
Frame Name : Big.Seven Carbon Comp R12
Fork : Fox 32 Float 27 CTD Remote ready O/C (1.5T) - Evo 100
Derailleur Front : Shimano Deore XT HD triple
Derailleur Rear : Shimano Deore XT Shadow
Shifter Front : Shimano Deore XT ispec
Shifter Rear : Shimano Deore XT ispec
Brake Lever : Shimano SLX
Brake Front : Shimano M596 180 mm Cen
Brake Rear : Shimano M596 160 mm Cen
Chainwheel : Shimano Deore XT 40-30-22
Bbset : attached
Chain : KMC X10 10s
Hub Front : Shimano Deore Cen
Hub Rear : Shimano Deore Cen
Rim : Merida Big.Seven Pro D
Freewheel : Shimano CS-HG-10 11-36
Spokes : black stainless
Tires : Schwalbe Racing Ralph 27.5 Perf. 2.25 fold / Schwalbe Racing Ralph 27.5 Perf. 2.25 fold
Handlebar Stem : Merida Pro Carbon -5°
Handlebar : Merida Pro OS 660 Flat
Headset : Big Conoid A-Bearing
Seat Post : Merida Carbon H SB0 27.2 mm
Saddle : Selle Italia X1
Pedal : XC Alloy
Weight : 11.20 kg

Wednesday, November 27, 2013

Merida Big Nine Carbon 1000



Colors : silk UD Carbon, orange, red
Framesizes : 15" / 17"
Frame Name : Big.Nine Carbon Comp
Fork : Manitou Marvel Comp 29 TS Air 100 taper
Derailleur : FrontShimano SLX HD triple
Derailleur : RearShimano Deore XT Shadow
Shifter : FrontShimano SLX ispec
Shifter : RearShimano SLX ispec
Brake : FrontShimano M615 180 mm Disc
Brake : RearShimano M615 160 mm Disc
Chain wheel : Shimano M622 40-30-22
Chain : KMC X10 10s
Rim : Mavic CrossRide Disc 29
Freewheel : Shimano CS-HG-10 11-36
Tires : Maxxis CrossMark 29er 2.1 fold / Maxxis CrossMark 29er 2.1 fold
Handlebar Stem : Merida Pro K OS -16°AD
Handlebar : Merida Pro OS 660 Flat
Headset : Big Conoid A-Bearing
Seat Post : Merida Carbon H SB0 27.2 mm
Saddle : ProLogo Kappa Evo
Pedal : XC Alloy
Weight : 11.40 kg

Merida Big Seven Carbon 3000

Colors: UD Carbon, red
Framesizes: 15"/17"
Frame Name: Big.Seven Carbon Comp R12
Fork: Fox 32 Float 650B CTD Remote-Ready O/C (1.5T, 15QR) - Evo 100
Derailleur Front: Shimano Deore XT HD double
Derailleur Rear: Shimano Deore XT Shadow+
Shifter Front: Shimano Deore XT ispec
Shifter Rear: Shimano Deore XT ispec
Brake Lever: attached
Brake Front: Shimano Deore XT-Fin 180 mm ice Disc
Brake Rear: Shimano Deore XT-Fin 160 mm ice Disc w/connect
Chainwheel: Shimano Deore XT 38-24
Bbset: attached
Chain: KMC X10 10s
Hub Front: attached
Hub Rear: RWS 12-142 axle
Rim: Fulcrum Red Power 27 XL F15-R12
Freewheel: Shimano CS-HG81-10 11-36
Spokes: attached
Tires: Schwalbe Racing Ralph 27 Evo 2.1 fold / Schwalbe Racing Ralph 27 Evo 2.1
Handlebar Stem: PRC Team OS -7°
Handlebar: FSA Afterburner Flat 685
Headset: Big Conoid A-Bearing Neck
Seat Post: PRC Double Carbon SuperLite 27.2 mm
Saddle: ProLogo Nago Evo X10 T2.0
Weight: 10.30 kg

Merida Big Nine Carbon XT Edition

Colors : silk UD Carbon, white, silver
Framesizes : 15" / 17"
Frame Name : Big.Nine Carbon Comp
Fork : Fox 32 Float 29 CTD Remote ready O/C (1.5T) - Evo 100
Derailleur Front : Shimano Deore XT HD triple
Derailleur Rear : Shimano Deore XT Shadow
Shifter Front : Shimano Deore XT ispec
Shifter Rear : Shimano Deore XT ispec
Brake Lever : attached
Brake Front : Shimano M596 180 mm Cen
Brake Rear : Shimano M596 160 mm Cen
Chainwheel : Shimano Deore XT 40-30-22
Bbset : attached
Chain : KMC X10 10s
Hub Front : Shimano Deore Cen
Hub Rear : Shimano Deore Cen
Rim : Merida Big.Nine Pro D
Freewheel : Shimano CS-HG-10 11-36
Spokes : black stainless
Tires : Schwalbe Racing Ralph 29 Perf. 2.25 fold / Schwalbe Racing Ralph 29 Perf. 2.25 fold
Handlebar Stem : Merida Pro Carbon -5°
Handlebar : Merida Pro OS 660 Flat
Headset : Big Conoid A-Bearing
Seat Post : Merida Carbon H SB0 27.2 mm
Saddle : Selle Italia X1
Pedal : XC Alloy
Weight : 11.20 kg
